Understanding the ISO 8583 Hex Structure#

An ISO 8583 consists of three main structural parts:

• Header and Message Type Identifier (MTI)
• Bitmaps
• Data Elements (Fields).

1
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

1
3033323849534f3830313030303030600000000131323130fef76d2188e1ea1c0000000000000011163532363433393939393939393939393939343434343000000000000034343434300000000000003434343432363035323031323232300000000001303030303030303130303033373932363035323031353232333832383130323630353230303532303630313138313838313830373232303036313130303030303030303030303131303030303030303030303032363035323034333931393530303030303030303030303030303030303130303030313130313233343536333033309f2701809f36020070

Getting the raw frames#

The socket runs over raw TLS — Burp Suite can’t intercept it because there’s no HTTP proxy protocol involved. Wireshark captures the packets but only sees encrypted bytes.

During APK analysis, a hidden flag was found: debugMode=false. I realized from apk code that when debug mode is enabled, it generates extensive logs for a lot of data. After decompiling with apktool, flipping the flag, re-signing, and reinstalling — the app printed the raw hex of every ISO 8583 frame to its logs. No interception needed. so I just grabbed the hex directly from the logs and used it as-is.

Connecting to the Socket#

With help from my friend Hassan Mohsen and AI, we managed to write a small Python script that could connect directly to the socket, authenticate, and send raw ISO 8583 frames.

Step 1 — Login: A standard HTTPS POST to the login endpoint with credentials returns a JWT token. Nothing unusual here — same as any REST API login.

1
# POST credentials to REST endpoint → receive JWT
2
jwt = http_login(login_url, username, password, serial)

Step 2 — Open TLS socket: Open a raw TCP connection to the processor’s host and port, then wrap it in a TLS context.

1
# Raw TCP connection wrapped in TLS
2
# Certificate verification disabled (same as app debug mode)
3
sock = open_tls_socket(host, port)

Step 3 — Send AUTH frame: The auth frame has a specific structure: a 4-byte length prefix, followed by the literal bytes AUTH, a 4-digit length indicator for the JWT, then the JWT itself. The server reads this, validates the token, and responds with AUTHOK.

1
# Frame structure: 4-byte length + "AUTH" + 4-digit JWT length + JWT
2
jwt_b = jwt.encode("utf-8")
3
payload = b"AUTH" + f"{len(jwt_b):04d}".encode() + jwt_b
4
frame = f"{len(payload):04d}".encode() + payload
5
sock.sendall(frame)
6
# → AUTHOK

Step 4 — Send ISO 8583 frames: After AUTHOK, the socket accepts raw ISO 8583 frames. Each frame is the hex payload prefixed with a 4-byte ASCII length. The server responds with the corresponding response message.

1
# Each frame = 4-byte ASCII length prefix + raw ISO 8583 bytes
2
sock.sendall(data)

This is the same flow the POS app uses — reconstructed from the decompiled code and the debug logs. The key insight is that once you have the auth flow and a valid payload, you can interact with the processor as if you were a legitimate terminal.

1
┌─────────────────────────────────────────────────────┐
2
│                    POS App                          │
3
└──────────────┬──────────────────────────────────────┘
4
               │ 1. POST /login (credentials)
5
               ▼
6
┌─────────────────────────────────────────────────────┐
7
│                  REST API                           │
8
└──────────────┬──────────────────────────────────────┘
9
               │ 2. ← JWT token
10
               │
11
               │ 3. Open TLS socket
12
               ▼
13
┌─────────────────────────────────────────────────────┐
14
│             Payment Processor Socket                │
15
│                   :5001 / TLS                       │
16
└──────────────┬──────────────────────────────────────┘
17
               │ 4. → AUTH frame (JWT)
18
               │ 5. ← AUTHOK
19
               │
20
               │ 6. → ISO 8583 frame (payment)
21
               │ 7. ← ISO 8583 response (DE39=00)
22
               ▼
23
┌─────────────────────────────────────────────────────┐
24
│                    Bank/Issuer                      │
25
└─────────────────────────────────────────────────────┘

Screen from the tool

Once I could read the responses, I started working through a checklist of everything worth testing.

There are some tools you can use, but they didn’t work for me.

• https://github.com/adelbs/ISO8583
• https://jpos.org/

1. Access Controls#

• Unauthenticated Socket Connection: Connect to the socket without sending any AUTH frame or credentials, then send a raw payment request.
  • What to look for: Does the server reject the request, or process it silently?
• Cross-Merchant Void Replay: Execute a Pay transaction under Merchant A. Capture the corresponding Void hex frame. Authenticate into the socket using Merchant B’s credentials and replay Merchant A’s Void frame.
  • What to look for: Does the server cross-authorize the Void, or validate that the requesting session owns the RRN?
• Parameter Tampering: Modify DE41 (Terminal ID) and DE42 (Merchant ID) in a Void or Refund payload to point to a different merchant, while authenticated as the original merchant.
• Forged / Non-Existent RRN: Send a Void or Refund using a random, forged, or non-existent RRN (e.g. 000000000000), or an RRN belonging to a different account.
  • What to look for: Does the server validate that the RRN exists and belongs to the current session before processing?

2. Logic Flaws#

• Replay Attack: Re-submitting the exact same raw hex payload (same STAN and same RRN) within seconds. The backend failed to return the cached response, processed the request again, and debited the amount a second time, creating a double-spending flaw on the dashboard.
  • What to look for: Does the server return the cached response, or does it process the request again and debit the amount a second time?
• Timed replay Attack: Captured a payment request and replayed it after waiting for the deduplication window to expire.
  • What to look for: Does the server treat the request as new after the window expires?
• Card Identity Bypass on Void and Refund: Initiate a Void or Refund, and when the terminal prompts for the original card, insert a different card. Then bypass the UI entirely and send the raw hex directly over the socket with a randomized card number.
  • What to look for: Does the server compare the PAN in the reversal request against the PAN on the original transaction, or only validate the RRN?
• Amount manipulation. Modified DE4 in a Refund payload to request an amount greater than the original purchase. Tested what happens when the numbers don’t add up.
  • What to look for: Does the server enforce that refund amounts can’t exceed the original transaction?
• Zero and negative value fuzzing. Sent transactions with 000000000000 in the amount field, and negative values, to see how the parser handled them.
  • What to look for: Parser errors, unexpected approvals, or state corruption at edge-case amounts.
• Cross-currency switching. Changed the currency code fields mid-transaction to see if a transaction started in one currency could be settled in another.
  • What to look for: Can a transaction started in one currency be settled in another? Does the server enforce currency consistency?
• MTI confusion. Took a valid Void payload and changed the MTI to 0420 (Reversal Advice) for an already-settled transaction, then watched whether the dashboard treated it as a reversal and changed the transaction state.
  • What to look for: Does the server re-process the transaction as a reversal? Does the dashboard change the transaction state?

3. Packet Structure and Parser Robustness#

• Variable-length boundary fuzzing. Locate LLVAR or LLLVAR fields — including EMV tags like 9F26, 9F37 — and set the length indicator higher than the actual data (padding with zeros or garbage). Then the reverse: set the length indicator shorter than the actual data.
  • What to look for: Parser panics, buffer overreads, field misalignment on subsequent fields, or server crashes.
• Bitmap desynchronization. Remove a required financial field from the payload while leaving its corresponding bit set in the bitmap. Then do the reverse: clear the bit but include the field data.
  • What to look for: Does the server’s field parser and bitmap parser stay synchronized, or does the inconsistency cause a misparse of subsequent fields?

1. Replay Attack — Timed Window Bypass:#

The server implements a short in-memory deduplication window. Within that window, sending the same frame twice returns the cached response. But once the window expires, the server has no memory of the original request — and approves the replay as a brand new transaction.

I captured a payment request, waited for the window to expire, and replayed the same raw hex. A new approved entry appeared on the dashboard. The card was effectively charged twice for a single transaction.

Impact: An attacker with access to captured socket traffic can re-submit any past transaction after the window expires, charging a card multiple times for the same purchase.

2. IDOR — Cross-Merchant Transactions:#

The server accepted Void and Refund requests without validating that the RRN in the request actually belonged to the authenticated merchant.

I authenticated into the socket using Merchant B’s credentials — a completely different username and password — then sent a Void request referencing an RRN that belonged to a transaction made under Merchant A. The server approved it. The dashboard showed the Void logged under Merchant B’s session, against Merchant A’s original transaction.

No field tampering was needed. The RRN alone was enough — the server never checked whether the transaction behind that RRN was owned by the merchant making the request.

Impact: Merchant A can void or refund Merchant B’s transactions.

3. Unauthenticated Transaction Processing with Ghost Logging#

I connected to the socket without sending any AUTH frame, then sent a raw payment request directly. The server processed the request, returned DE39 = 00, and incremented the internal transaction counter. But when I checked the admin dashboard — nothing. No entry in the transaction log, no record in the merchant history, no audit trail anywhere. The transaction existed in the system’s internal state but was completely invisible to every monitoring surface.

Impact: An attacker can process transactions that leave no trace. From a forensics perspective, if this were exploited in production, there would be no way to detect or investigate the activity after the fact.

4. Missing Cardholder Verification on Void/Refund#

This one required a specific sequence:

1. Performed a Pay transaction using Card A — approved, appeared on dashboard
2. Initiated a Void on that transaction
3. When the terminal prompted for the card, inserted Card B instead
4. Terminal displayed a card mismatch error and dropped the request — it never reached the socket
5. But the raw hex of the Void request was already printed in the APK debug logs
6. Copied that hex and sent it directly over my own socket connection
7. Server returned DE39 = 00 — Approved

Impact: anyone with POS access can reverse any transaction using any card.

The mock server’s replay vulnerability made testing easy because I could reuse the same hex baseline. However, if the server isn’t vulnerable to replays, you can still test the rest of the checklist. Simply intercept a fresh, real-time raw hex frame right before it leaves the terminal, and immediately send/modify it directly through your custom socket script to bypass the terminal UI.
